Library of Crystallographic Prototypes

Basis vectors:

\[ \begin{array}{ccccccc} & & \mbox{Lattice Coordinates} & & \mbox{Cartesian Coordinates} &\mbox{Wyckoff Position} & \mbox{Atom Type} \\ \mathbf{B_1} & = & 0 \, \mathbf{a}_{1} + 0 \, \mathbf{a}_{2} + 0 \, \mathbf{a}_{3} & = & 0 \mathbf{\hat{x}} + 0 \mathbf{\hat{y}} + 0 \mathbf{\hat{z}} & \left(2a\right) & \mbox{Mo} \\ \mathbf{B_2} & = &y_{2} \, \mathbf{a}_{1}+ x_{2} \, \mathbf{a}_{2}+ \left(x_{2} + y_{2}\right) \, \mathbf{a}_{3}& = &x_{2} \, a \, \mathbf{\hat{x}}+ y_{2} \, a \, \mathbf{\hat{y}}& \left(8h\right) & \mbox{Ni} \\ \mathbf{B_3} & = &- y_{2} \, \mathbf{a}_{1}- x_{2} \, \mathbf{a}_{2}- \left(x_{2} + y_{2}\right) \, \mathbf{a}_{3}& = &- x_{2} \, a \, \mathbf{\hat{x}}- y_{2} \, a \, \mathbf{\hat{y}}& \left(8h\right) & \mbox{Ni} \\ \mathbf{B_4} & = &x_{2} \, \mathbf{a}_{1}- y_{2} \, \mathbf{a}_{2}+ \left(x_{2} - y_{2}\right) \, \mathbf{a}_{3}& = &- y_{2} \, a \, \mathbf{\hat{x}}+ x_{2} \, a \, \mathbf{\hat{y}}& \left(8h\right) & \mbox{Ni} \\ \mathbf{B_5} & = &- x_{2} \, \mathbf{a}_{1}+ y_{2} \, \mathbf{a}_{2}+ \left(y_{2} - x_{2}\right) \, \mathbf{a}_{3}& = &y_{2} \, a \, \mathbf{\hat{x}}- x_{2} \, a \, \mathbf{\hat{y}}& \left(8h\right) & \mbox{Ni} \\ \end{array} \]
